HOBO Temperature/Relative Humidity (RH) Data Node

Reference ZW-003

The HOBO® ZW-003 is a two-channel wireless data node with an integrated temperature and relative humidity sensor. It wirelessly transmits data in real time, reducing the costs and inconvenience associated with manual data offload.

Description
Attachments

Highlighted Features

    Wirelessly transmits real-time temperature and relative humidity data
    Compact size for easy deployment wherever data is needed
    Notifies you of alarm conditions via email or text messages
    Onboard buffer memory helps prevent data loss
    Powerful HOBOware® Pro software for organizing and viewing data (included with HOBO data receiver)

A complete system requires at least one wireless HOBO data node, HOBO data receiver (ZW-RCVR), and HOBOware Pro software (included with ZW-RCVR). Depending on your system deployment, a HOBO data router (ZW-ROUTER) may be required.

The ZW-003 data logger supports the following measurements: Relative Humidity and Temperature

Buffer memory: approx. 4k measurements
Sample rate: 1 min to 18 hrs
Transmission rate: 2 min and greater
Power options: AC power adapter, battery backup

Measurement Range
Temp: -20 to 70°C (-4 to 158°F) when line powered, -20 to 50°C (-4 to 122°F) when battery powered.
RH: 5 to 95% RH (non-condensing)

Accuracy
Temp: ±0.54°C typical over 0 to 50°C (±0.97° F over 32 to 122°F) when line powered, ±0.21°C over 0 to 50°C (±0.38°F over 32 to 122°F) when battery powered.
RH: ± 2.5 % from 10% to 90% typical to a maximum of ±3.5% including hysteresis at 25°C (77°F); below 10% and above 90% ±5% typical

Operating Range
Temp: -20 to 50°C (-4 to 122°F) when battery powered, -20 to 70°C (-4 to 158°F) when line powered.
RH: 5%-95% non-condensing

Resolution
Temp: 0.02° C @ 25° C (0.04° F @ 77° F)
RH: 0.05%

Response Time
Temp: 5 min. in air moving 1 m/sec
RH: 10 min. in air moving 1 m/sec

Range: Approx.100m (300ft.) depending on obstructions or interference
Weight: 138g (4.87 oz) with batteries
Dimensions: 96.5 x 108 x 28mm (3.8 x 4.25 x 1.1 in)
Radio power: 1.6 mW (2 dBm)
Wireless data standard: IEEE802.15.4 2.4 GHz band

CE - The CE Marking identifies this product as complying with all relevant directives in the European Union (EU)

ZW-003 Datasheet

Download (66.17k)
